SMART Whole House Water Filter System (4-6 people)

Multi-Media Whole House Water Filter System with Controller, CQE-WH-01114

Show Picture 1Show Picture 2Show Picture 3Show Picture 4

Click here to view larger image

1.5 cu.ftSKU: CQE-WH-01114
2 - 3.5 bathrooms.
Capacity: 1,000,000 gallons.
Weight:80 LBS.
Price: $1,675.00
2.0 cu.ftSKU: CQE-WH-01115
3.5 - 6 bathrooms.
Capacity: 1,500,000 gallons.
Weight:100 LBS.
Price: $1,960.00
Ships in 3-5 days

Filter cartridge(s) included.

SMART Multi-Media Water Purification System for Home provides you with great tasting water. Filter removes hundreds of contaminants from water. System comes in three different sizes for small, medium and large homes. Great for home, office or light commercial use. With automatic backwashing, system cleans itself on specified intervals set by the electronic controller to keep it in top performing condition.

Filtration Stages

This unit is installed where main line enters your house, and provides Clean Drinking Water everywhere in your home!
Crystal Quest Multi-Media Home Water Filter has 5 stages of filtration:
  • First stage, water flows through a 20" sediment filter cartridge that removes sediment, silt, sand and dirt. Also extends the life of the water filter and prevents damage
  • In stages 2 and 3,water flows through 2 beds of Redox (Oxidation/reduction process, also known as KDF ) media made of a special high-purity alloy blend of two dissimilar metals - copper and zinc. Representing a new and unique way of water processing medium which by its natural process of electrochemical oxidation/reduction and adsorption action reduces and/or remove many unwanted contaminants from water. It is a major advancement in water treatment technology that works on electro-chemical and spontaneous-oxidation-reduction (REDOX) principles. Chlorine is instantaneously and almost inexhaustibly oxidized. Iron and hydrogen sulfide are oxidized into insoluble matter and attaches to the surface of the media. Heavy metals such as lead, mercury, copper, nickel, chromium, cadmium, aluminum, and other dissolved metals are also removed from the water by this natural process of electrochemical process. They are attracted to the surface of the media, much like a magnet. The media also prevents bacteria from growing throughout the entire unit.
  • In stage 4, water passes through granulated activated carbon (GAC). GAC is universally recognized and widely used as an effective adsorbent for a wide variety of organic contaminants, such as chlorine (99.9%), chemicals linked to cancer (THM's, benzine), pesticides, herbicides, insecticides, volatile organic compounds (VOC's), PCB's, MTBE's and hundreds of other chemical contaminants that may be present in water, bad taste, and odors from your drinking water.
  • In stage 5 water flows through a 20" solid carbon cartridge for removing Volatile Organic Compounds (VOC's, insecticides, pesticides and industrial solvents).
Want to have safe drinking water when the next West Virginia chemical spill hits? This unit can be configured to remove 4-methylcyclohexane methanol, or Crude MCHM. Ask us if this is what you are looking for.

System Features:

  • The system connects to the main line of your home
  • Easy Filter Changes
  • Media in the tank can be replaced
  • Shipped with filtration media already in the tank , ready to be installed


  • Maximum Flow Rates: 1 cu.ft - 9 GPM, 1.5 cu.ft. 10-11 GPM, 2 cu.ft 11-13 GPM (gallons per minute)
  • Easy to replace media approximately every 4-7 years for 1,000,000 and 5-8 years for 1,500,000 gallons unit
  • Requires only periodic backwash to keep unit in top condition (typically once or twice a month).
  • Available in 3/4" and 1" NPT (input/output water line diameter)
  • Low voltage transformer, will produce filtered water even with power off.
Fleck 5600
Self-backwashing -industry standard Fleck microprocessor with LED display. At scheduled by you intervals, backwash automatically removes some contaminants trapped within the media bed and washes them down the drain (drain line is not included).

Bypass Valve
3/4" or 1" Stainless Steel bypass valve - please specify water line diameter at Checkout!

Product numbers:
1,000,000 gallons CQE-WH-01114 ; 1.5 million gallons CQE-WH-01115
