View CartUnder Sink Water Filter Without Cartridge
   |
Ships in 2-3 days | ||||||||||||||||||||||||
Undersink Water Filter no Cartridge by Crystal Quest is a 6-stage disposable filtration system. The multi-stage process includes a combination of Coconut Shell Carbon or Granulated Activated Carbon(GAC) and Eagle Redox Alloy media which increases the systems' effectivity in removing hundreds of other contaminants from your water. This solid state water filter uses the latest technologies that blend the adsorption capabilities of coconut shell activated carbon with KDF media and more. This unit can be back washed. Semi annually back washing of the unit not only ensures balanced filtration and eliminates the potential for channeling, but also back-flushes the unit. Designed in an attractive white housing, it installs neatly under the sink. Quick and easy to install and use, attractive, convenient, and effectively removes many contaminants from water. The perfect solution for any household.
Key Features and Benefits:
- 6-stage filtration with no cartridges to replace.
- Back washable.
- Quick connect fittings for easy installation.
- Easy install kit includes necessary installation hardware.
- Variable multi-stage filter option for different filtration capacity.
Contaminants Reduced:
| • Aluminum | • Copper | • E. Coli | • Lead | • Sand |
| • Bacteria | • Cryptosporidium | • Fecal Coliform | • Mercury | • Sediment |
| • Cadmium | • Cysts | • Giardia | • Nickel | • Silt |
| • Chromium | • Streptococcus/Enterococcus Faecalis | • Heavy Metals | • Salmonella | • Dirt |
Filter Configurations:
| SKU | Filtration Capacity | Filter Life | |
|---|---|---|---|
| PLUS | CQE-US-00300 | 10,000 gallons | 1-3 years |
| ULTRA | CQE-US-00301 | 20,000 gallons | 2-4 years |
| ULTIMATE | CQE-US-00302 | 30,000 gallons | 3-5 years |
Specifications
| Model/SKU: | CQE-US-00300, CQE-US-00301, CQE-US-00302 |
| Manufacturer ID: | CQE-US-00300, CQE-US-00301, CQE-US-00302 |
| Dimensions (LxHxW): | 3.5"L x 10.5"H x 3.5"W |
| Filtration Capacity: | PLUS-10,000/ ULTRA-20,000/ ULTMATE-30,000 gallons |
| Design Flow Rate (Gallons per Minute, gpm): | 0.5 gpm |
| Media: | Sediment filter pads, Eagle Redox Alloy, Granulated Activated Carbon(GAC) |
| Operating Temperature (°F): | 40°F - 90°F |
| Operating Pressure(PSI): | 20 psi - 60 psi |
| Fitting Size (inches): | 1/4"(Also available in 3/8") |
| End Caps: | Polypropylene #5 |
| Inner/Outer Wraps: | Polyolefin |
| Netting: | Food Grade High-density Polyethylene |
| Gaskets: | Buna-N |
| Weight(lbs): | 6 lbs |
* if 3/8" needed, additional conversion package should be ordered.
PRODUCT NOTE:
- When considering installation, if current under sink plumbing is hard copper tubing the saddle valve would be used; for flex tubing the T-valve would be required. While ordering, Please note the type of tubing used to ensuire compatibility.
- Includes multi-stage reduction filter, faucet, filter wrench, installation hardware.
- Patents Pending: Patent Pending 60-775,029/ 60-775,030/ 60-775,032
PRODUCT NOTE:
- When considering installation, if current under sink plumbing is hard copper tubing the saddle valve would be used; for flex tubing the T-valve would be required. While ordering, Please note the type of tubing used to ensuire compatibility.
- Includes multi-stage reduction filter, faucet, filter wrench, installation hardware.
- Patents Pending: Patent Pending 60-775,029/ 60-775,030/ 60-775,032
Documents
 Influent (unfiltered) Water test results (pdf) |
0.1 MB |
|
Disposable Filter Water test results (pdf) |
0.1 MB |
|
Under Sink Disposable Water Filter Manual (pdf) |
1.32 MB |
